PRODUCT
MAIN FEATURES
1. Hydraulic double drum vibratory rollers are manufactured according to international advanced technology and by use of imported main components abroad, suitable for compaction of various stabilized soils, bituminous concrete and rolling cement concrete on road surface construction, also for compaction of road base course, which are universal compaction equipments for high-class highway, airport, harbors, dams, municipal road and industrial ground.
2. Leading brand Kubota engine (Japan) with large power storage, reliable performance, to reach EU II emission standard.
3. Hydrostatic travel and vibration drive in both drums with greater gradeability. High vibration frequency with great excited force for better road surface quality.
4. Hydrostatic center articulated steering, infinitely variable speeds for convenient of operation. The emergency stop push button assures safety and dependability of the machine.
5. The original imported hydraulic components as Sauer travel pump (USA), Poclain travel motor (France), Centa shaft coupler guarantees the good performance of the whole machine.
6. Compact design of small size and beautiful appearance, it is suited for compaction of narrow areas. Completely open engine cover offers the optimal space of maintaining.
TECHNICAL SPECIFICATION
|
Item |
R26S |
|
Drive Mode |
Full-wheel |
|
Engine |
CUMMINS CHINA |
|
Model |
6CTA8.3 |
|
Rated power (kW) |
160 |
|
Operating Weight (kg) |
26000 |
|
Static Line Force (N/cm) |
736 |
|
Vibration Amplitude (mm) |
2.0/1.0 |
|
Vibration Frequency (Hz) |
28/35 |
|
Centrifugal Force (kN) |
420/340 |
|
Max. Travel Speed(Km/h) |
9 |
|
Gradeability (%) |
45 |
|
Turning Radius (mm) |
7500 |
|
Drum Width (mm) |
2130 |
|
Drum Diameter (mm) |
1650 |
|
Wheelbase (mm) |
3500 |
|
Ground Clearance (mm) |
470 |
|
Overall Dimension (mm) |
6540x2392x3048 |
