Main Feature:
1. Intelligent spraying control, high accuracy, wide spray area, minimum spray rejection.
2. long-reach spray boom allows to work at long distance and great height.
3. 3-PRS spray head gives full spherical spray area without blind spot
4. Full hydraulic intelligent spray boom guarantees no interference when all boom sections working at the same.
5. Rigid chassis, internal combustion – hydrostatic transmission, 4-wheel drive, 4-wheel steering with swiveling driver’s cab.
6. 4 hydraulic supporting leg hold the vehicle steady at all times, absorb forces when material blending, pumping and spraying.
7. Advanced undamped hydraulic system with 1200mm stroke length offers high and steady pumping pressure, also reduce power consuming and parts wearing.
8. Pumping capacity range from 0 to 60 cubic meters. It can be adjusted as per customer requirements to satisfy complicated working conditions. (Recommend capacity range is 4 to 28 cubic meters)
9. Complete manual control on vehicle and compact full function wireless remote control; Protection of overvoltage and low voltage; Double safety emergency stop
10. Computerized man-machine communication module: Input and record spray operation data; display real time running condition and running data; failure report; PLC controlled hydraulic system; concrete pump and dosing pump synchronously program-controlled.
11. Compact and sturdy wireless remote control offers unlimited movement control to the spray boom and nozzle operator
12. Reliable frequency convert technology complied with PLC and computer control offer a setting control of adding rate depending on concrete out put. Auto-adjusting frequency control offers motor speed change and auto dosing according to concrete delivery amount
13. Minimum height and rotation radius, suitable for space limited work sites.
TECHNICAL SPECIFICATIONS
|
NO
|
Term
|
Data
|
|
1
|
Concrete delivery pipe dimension
(outer dia. X pipe thickness)
|
Φ89 x 4.5mm
|
|
2
|
Concrete pump capacity
|
4-28 m³/h
|
|
3
|
Setting accelerator delivery capacity
|
0-850Kg/h
|
|
4
|
Setting accelerator tank
|
800L
|
|
5
|
Air compressor
|
0-0.7MPa
|
|
6
|
Max. wind flow
|
10.6 m³/min
|
|
7
|
Transmission
|
4-wheel drive
|
|
8
|
Travelling speed
|
0-15Km/h
|
|
9
|
Steering
|
4-wheel steering / front wheel steering
|
|
10
|
Outside dimension (L*W*H)
|
8000 x 2500 x 3200mm
Travelling
|
|
11
|
Outside dimension (L*W*H)
|
8000 x 2500 x 3200mm
Working
|
|
12
|
Power
|
380V/50Hz
|
|
13
|
Power cable length
|
50m
|
|
14
|
Electric current
|
400A
|
|
15
|
Cleaning machine pressure
|
20MPa
|
