CPC(D)20-35 ISUZU

Share This Product:

BRIGHT SPOT OF PRODUCT

MAIN FEATURES

1. Enhanced comfort through innovative design.

2. Hydraulic transmission and mechanical transmission types are all available.

3. Flexible steering and small turning radius, with full Hydraulic Steering System.

4. We use scientific ergonomic method to design Forklift truck. The operation space has been efficiently enlarged. The rough feeling of the driver has been reduced to the lowest extends.

5. A variety of domestic and imported engines for you to choose. The emission meets EC and EPA new regulation.

6. Specially designed container door frame can enter the container for operation. This series forklifts can be equipped with two, or three full free lift mast, and various attachments, according to user’s demand.

7. Enclose cabin is made of assembling plate on overhead guard, high strength overhead is design to ensure the safety.

8. Operator presence sensing system, the system will cut off the driving force to prevent accidents, when the driver leave the seat during operation.

TECHNICAL SPECIFICATION

Features	Model		Power shift T/M	CPCD20	CPCD25	CPCD30	CPCD35
	Model		Manual shift T/M	CPC20	CPC25	CPC30	CPC35
	Load capacity		kg	2000	2500	3000	3500
	Load center		mm	500	500	500	500
	Power unit			diesel	diesel	diesel	diesel
	Operator type			Driver/seat	Driver/seat	Driver/seat	Driver/seat
	Tire type		Front/rear	Pnenumatic	Pnenumatic	Pnenumatic	Pnenumatic
	Wheel		Front/rear	2/2	2/2	2/2	2/2
Dimension	Max. lifting height		mm	3000	3000	3000	3000
	Free lift		mm	160	160	150	150
	Fork size L×W×T		mm	1070×122×40	1070×122×40	1070×125×45	1070×125×50
	Tilt range Mast forward/backward		deg	6/12	6/12	6/12	6/12
	Overall length(without fork)		mm	2460	2530	2660	2720
	Total width		mm	1150	1150	1225	1285
	Mast height (fork lowering)		mm	1995	1995	2075	2075
	Overall height fork raised With backrest		mm	4030	4030	4250	4250
	Height to head guard		mm	2120	2120	2140	2140
	Turning raduis(outside)		mm	2170	2240	2400	2460
	Front face of fork to front axle		mm	450	450	480	485
	Right angle stacking aisle not add load length&clearence		mm	2615	2690	2880	2940
Performance	Speed	Max Travelling full/no load	km/h	17/19	17/19	18/19.5	18/19.5
		Lifting full/no load	mm/s	550/580	550/580	450/500	450/500
		Lowering full/no load	mm/s	450/550	450/550	450/450	450/420
	Max.drawbar pull	Power shift T/m full/no load	kg	1670/830	1670/830	1500/1000	2100/1000
	Max.drawbar pull	Manual shift T/M full/no load	kg	1700/830	1700/830	1550/1000	2100/1000
	Gradeability at 1.6km/h	Power shift T/m full/no load	%	27/20	23/18	18/20	18/20
	Gradeability at 1.6km/h	Manual shift T/M full/no load	%	21/20	18/18	18/20	18/20
Weight	Truck weight		kg	3330	3670	4290	4690
	Weight distribution	Full load front/rear	kg	4700/630	5410/760	6420/870	7300/890
	Weight distribution	No load front/rear	kg	1510/1820	1430/2240	1680/2610	1880/2810
Frame	Tires	Number	front/rear	2/2	2/2	2/2	2/2
		Model	front axle	7.00-12-12PR	7.00-12-12PR	28×9-15-12PR	28×9-15-12PR
		Model	rear axle	6.00-9-10PR	6.00-9-10PR	6.50-10-10PR	6.50-10-10PR
	Wheelbase		mm	1600	1600	1700	1700
	Tread	Front/rear	mm	970/970	970/970	1000/970	1060/970
	Ground clearence	At lowest point(mast)	mm	110	110	120	120
	Ground clearence	Frame	mm	115	115	135	135
	Brake	Service brake		Hydraulic-foot peda
	Brake	Parking brake		Mechanical-hand lever
Engine & transimission	Battery	Voltage/capacity	V/AH	12/80
	Engine	Model		ISUZU 4JG2
		Rated power	PS (kw/rpm)	61/2450 (44.8/2450)
		Rated torque	kg-m max.(N-m)	19/1800 (186/1800)
		number of cylinder	PC	4	4	4	4
		Placement	L	3.059	3.059	3.059	3.059
	Fuel tank capacity		L	70	70	70	70
	Transmission	Speed forward/backward	Power shift T/M	1-1 power shift T/M
	Transmission	Speed forward/backward	Manual shift T/M	2-2 manual shift T/M
	Operating pressure	Hydraulic system pressure	kg/cm²	180	180	180	180
