Technical parameters |
|||||
|
Model |
|
CPD10 |
CPD15 |
CPD20 |
CPD25 |
|
Load capacity |
kg |
1000 |
1500 |
2000 |
2500 |
|
Load center |
mm |
500 |
500 |
500 |
500 |
|
Max lifting height |
mm |
3000 |
3000 |
3000 |
3000 |
|
Tilting angles (forward-backward) |
|
6°/12° |
6°/12° |
6°/12° |
6°/12° |
|
Lifting speeds(with load/without load)mm |
mm/s |
440/320 |
480/300 |
430/280 |
420/260 |
|
Free lift |
mm |
135 |
135 |
160 |
160 |
|
Max Driving seeds(with load/without load ) |
km/h |
13.5 |
13 |
11.5 |
11 |
|
Min turning radius |
mm |
1850 |
1885 |
2320 |
2320 |
|
Slope-climbing gradient |
|
15% |
15% |
10% |
10% |
|
Length |
mm |
2915 |
2950 |
3335 |
3485 |
|
Width |
mm |
1086 |
1086 |
1180 |
1180 |
|
Height |
mm |
2100 |
2100 |
2180 |
2180 |
|
Mast height fork lowered |
mm |
1990 |
1990 |
1995 |
1995 |
|
Overhead height fork raised |
mm |
4030 |
4030 |
3900 |
4030 |
|
Fork size L*W*T |
mm |
920*100*40 |
920*100*40 |
920*122*40 |
1070*122*40 |
|
Max lowering speeds |
mm/s |
Without load ≥300 |
Without load ≥300 |
Without load ≥300 |
Without load ≥300 |
|
|
|
|
|
||
|
With load ≤600 |
With load ≤600 |
With load ≤600 |
With load ≤600 |
||
|
Fork overhang |
mm |
435 |
435 |
490 |
490 |
|
Wheel base |
mm |
1250 |
1250 |
1500 |
1500 |
|
Rear overhang |
mm |
335 |
370 |
395 |
395 |
|
Lateral fork adjustment |
mm |
200-970 |
200-970 |
245-1038 |
245-1038 |
|
Under –clearance |
mm |
105 |
105 |
110 |
110 |
|
Tread front |
mm |
890 |
890 |
980 |
980 |
|
Tread rear |
mm |
920 |
920 |
950 |
950 |
|
Battery voltage |
v |
48 |
48 |
48 |
48 |
|
Battery capacity |
Ah |
400 |
400 |
620 |
700 |
|
Traveling motor |
Kw |
5 |
5 |
8 |
8 |
|
Lifting motor |
Kw |
7.5 |
7.5 |
8.6 |
10 |
|
Steering motor |
Kw |
0.8 |
0.8 |
|
|
|
Tire front |
|
6.5-10-10PR |
6.5-10-10PR |
7.00-12-12PR |
7.00-12-12PR |
|
Tire rear |
|
5.00-8-10PR |
5.00-8-10PR |
18X7-8-14PR |
18X7-8-14PR |
|
Total weight |
kg |
2650 |
2950 |
4150 |
4420 |
|
Electronic controllers |
|
Ge/GURTIS/ZAPI |
Ge/GURTIS/ZAPI |
Ge/CURTIS/ZAPI |
Ge/CURTIS/ZAPI |
