MAIN FEATURES
1. Reliable and durable frame work prolong the machine using life.
2.The original imported engine generates super power and low exhaust.which makes the macine environmental.
3.Optimum hydraulic system design grantee efficient work.
4.The integral FOPS & ROPS and human-engineering designed cabin makes work comfortable.
5.Adopting internationally univeral quick coupler can make changing attachments in few minutes.
6.Convenient maintenance.
7.High flow double output
TECHNICAL SPECIFICATION
| Item | SSL1050 | |
| Rated operating capacity | kg | 1050 |
| Tipping load | kg | 2100 |
| Bucket capacity | m3 | 0.6 |
| Operating weight | kg | 3500 |
| Max. travel speed | km/h | 12/18 |
| Hydraulic pump flow | L/min | 75/125 |
| Fuel tank capacity | L/min | 60/90 |
| Overall dimensions | mm | 3560*1900*2050 |
| Height at maximum extension | mm | 4070 |
| Height to bucket hinge pin | mm | 3150 |
| Width with bucket | mm | 1900 |
| Track width | mm | 1500 |
| Wheelbase | mm | 1185 |
| Ground clearnce | mm | 200 |
| Dump angle | ° | 40 |
| Dumping height | mm | 2450 |
| Engine model | Deutz D226B-4 | |
| Net power | 75HP/2500rpm | |
| Type | 4 Cylinder in-line.water cooled.4 stroke. Diesel engine | |
| Displacement | L | 3.9 |
