PRODUCT
MAIN FEATURES
1. Innovative One-piece mainframe
2. Closed circuit hydraulic system
3. World famous engine generates enough power for all jobs
4. Bigger lifting height
5. When the boom is lifting, the bucket automatically keeps levelling.
TECHNICAL SPECIFICATION
| Item | SSL700 | |
| Rated operating capacity | kg | 700 |
| Tipping load | kg | 1400 |
| Bucket capacity | m3 | 0.3-0.456 |
| Operating weight | kg | 3000 |
| Max. travel speed | km/h | 12 |
| Hydraulic pump flow | L/min | 62.5 |
| Fuel tank capacity | L/min | 50 |
| Overall dimensions | mm | 3200*1740*2030 |
| Height at maximum extension | mm | 3670 |
| Height to bucket hinge pin | mm | 2900 |
| Width with bucket | mm | 1740 |
| Track width | mm | 1450 |
| Wheelbase | mm | 991 |
| Ground clearnce | mm | 185 |
| Dump angle | ° | 40 |
| Dumping height | mm | 2310 |
| Engine model | XINCHAI 490 | |
| Net power | 50HP/2650rpm | |
| Type | 4 Cylinder in-line,water cooled,4 stroke, Diesel engine | |
| Displacement | L | 2.54 |
