Engine |
||
|
Model |
|
LR4108T4X |
|
Type |
|
Vertical, water-cooled, four-stroke, direct injection economy diesel engine |
|
Rated rotation speed |
r/min |
2300 |
|
Transmission system |
||
|
Number of speed gears, forward / reverse |
|
12/4 |
|
Speed range, forward |
km/h |
1.94-31.92 |
|
Speed range, reverse |
km/h |
5.01-15.03 |
|
Machine body |
||
|
Wheel base |
mm |
2342 |
|
Front wheel tread |
mm |
1400-1900 |
|
Rear wheel tread |
mm |
1500-2100 |
|
Min. turning radius |
m |
3.9 |
|
Max. operating weight |
kg |
3425 |
|
Specific fuel consumption under rated conditions |
g/kW.h |
≤242 |
|
Tyres, front / rear |
|
7.5-16/14.9-30 |
|
Max. lifting capacity |
kN |
16.5 |
|
PTO shaft type |
|
Rear-positioned, independent and synchronous |
|
Max. tractive force |
kN |
22.4 |
|
Overall dimensions (L×W×H) |
mm |
4160*1878*2820 |
|
Min. ground clearance |
mm |
430 |
