MAIN FEATURES
1. Range of Application: For the transportation of 1×40ft container or 2×20ft
container or 1×20ft containers.At the rear there is a samall platform,so it is convenient for loading and unloafing one 20ft container.
2. Characters: The chassis consists of 2 I-beams and many supporting beams; with enough yield strength.
3. Main Components: LTD axle (Chinese brand) or BPW axle (German brand), FW landing gear (Chinese brand) or JOST landing gear (American brand), JOST kingpin, HALDAX valve (American brand) HALDAX ABS system, other parts are famous brands from Germany, Japan, US or UK.
TECHNICAL SPECIFICATION
|
Length |
7850 mm |
|
width |
2480 mm |
|
height |
1535 mm |
|
wheelbase |
5100+1300 mm |
|
Base between tyres |
1850 mm |
|
Rated load capacity |
29500 kg |
|
Kerb weight |
4100 kg |
|
Gross weight |
33600kg |
|
Load on the 5th wheel |
15600kg |
|
Back suspension |
820 mm |
|
Angle of departure |
32° |
|
Quantity of steel band spring |
8/8 |
|
Specification of tyres |
11.00-20 |
|
Quantity of tyre( without spare wheel) |
8 |
