MAIN FEATURES
1. Range of application: To transport the bulk cargo such as coal, sand and stones in a short or relatively long distance.
2. Characters: Underslung, great capacity, easy operating and low cost.
3. Main Components: HYVA hydraulic system (Netherlandish brand), LTD axle (Chinese brand) or BPW axle (German brand), FW landing gear (Chinese brand) or JOST landing gear (American brand), JOST kingpin, HALDAX valve (American brand) HALDAX ABS system, other parts are famous brands from Germany, Japan, US or UK.
TECHNICAL SPECIFICATION
|
Length |
13000 mm |
|
Width |
2440 mm |
|
Height |
1730 mm |
|
Platform dimensions |
12740×2440×1730mm |
|
Axle base |
7900+1300 mm |
|
Wheel base |
1850 mm |
|
Rated capacity |
32000kg |
|
Curb weight |
9200 kg |
|
Gross weight |
41200kg |
|
Rear overhang |
2870 mm |
|
Steelplate spring films |
8/8/8 |
|
Tyre size |
11.00R20 |
|
Tyre number |
8 |
|
Cylinder |
3 |
