MAIN FEATURES
1. Range of Application: For the transportation of container or other bulk cargo.
2. Characters: Safety brackets on front and rear baffles. The sidewalls divided into subsections by some vertical rods, and every subsection is available for open down.
3. Main Components: LTD axle (Chinese brand) or BPW axle (German brand), FW landing gear (Chinese brand) or JOST landing gear (American brand), JOST kingpin, HALDAX valve (American brand) HALDAX ABS system, other parts are famous brands from Germany, Japan, US or UK.
TECHNICAL SPECIFICATION
|
Length |
13000 mm |
|
Width |
2500 mm |
|
Height |
2818 mm |
|
Platform dimensions |
12740×2348×1518mm |
|
Axle base |
7900+1300 mm |
|
Wheel base |
1850 mm |
|
Rated capacity |
37000kg |
|
Curb weight |
8300 kg |
|
Gross weight |
45300kg |
|
Rear overhang |
2870 mm |
|
Steelplate spring films |
8/8/8 |
|
Tyre size |
11.00R20 |
|
Tyre number |
8 |
|
Side board height |
800mm |
