MAIN FEATURES
1. Range of Application: For the transportation of construction equipments, large scale equipments, steel products or other cargo.
2. Characters: Low-barycenter makes a good balance. The chassis consists of 2 I-beams and many supporting beams; with enough yield strength.
3. Main Components: LTD axle (Chinese brand) or BPW axle (German brand), FW landing gear (Chinese brand) or JOST landing gear (American brand), JOST kingpin, HALDAX valve (American brand) HALDAX ABS system, other parts are famous brands from Germany, Japan, US or UK.
TECHNICAL SPECIFICATION
|
Length |
18470 mm |
|
Width |
3000 mm |
|
Height |
2850 mm |
|
Platform dimensions |
14000×3000×1200mm |
|
Axle base |
12300+1350+1350+1350 mm |
|
Wheel base |
2150 mm |
|
Rated capacity |
64000kg |
|
Curb weight |
18000 kg |
|
Gross weight |
82000kg |
|
Rear overhang |
1670 mm |
|
Steelplate spring films |
8/8/8 |
|
Tyre size |
11.00R20 |
|
Tyre number |
16 |
